| Model | C15 |
| Type | Class D Switch Power |
| Number of amplifier channels | 4 Channel |
| Peak total output all channels driven | 9600w |
| 1KHz,0.01% THD+N Max.Output stereo mode 8Ω | 1500W*4ch |
| 1KHz,0.01% THD+N Max.Output stereo mode 4Ω | 2400W*4ch |
| 1KHz,0.01% THD+N Max.Output stereo mode 2Ω | 3000W*4ch |
| 1KHz,0.01% THD+N Max.Output bridge mode 8Ω | 4500W*2ch |
| 1KHz,0.01% THD+N Max.Output bridge mode 4Ω | 6000W*2ch |
| Performance | |
| Signal to Noise Ratio | -100dBA |
| Slew Rate | 40v/us |
| Frequency Response | ±0.1dB, 20Hz -20kHz |
| THD+N | Rated Power 8Ω/1kHz ≤0.01% |
| Damping Factor(5Hz-1KHz) | ≤350:1 |
| Default gain | Rated Power 8Ω 1V |
| Input Impedance(Balance / Unbalance) | ≥20k / ≥15K |
| Imput CMRR | ≤-75dB |
| Cross Talk(1kHz) | ≤-70dB |
| Indicators | Actect,Protect,Signal,Clip |
| Connecters | |
| Analog Input/Link | 4 x female Neutrik® XLR3 (IN) |
| SpeakOn Connecters | 2 x Neutrik® NL4 |
| SpeakOn Connecters | 1 x Neutrik® NL8 / 8-Pin PA-COM |
| Main Power Supply | 170V～220V，50Hz/60Hz |
| Physical data | |
| Dimensions（W x H x D） | 483 x 44 x 440 mm |
| Material | Metal |
| Finish | Black |
| Protection rating | IP2x |
| Weight | 11kg / 24.3Ib |
