| Type | Passive 2-way Coaxial Enclosure |
| Frequency Response(Preset) | 70Hz-20kHz(-10dB) |
| Horizontal | 110° |
| Vertical | 110° |
| Monitor Angle | 55°(1) 15°(2) |
| 0°(3) | |
| Drivers | LF：1×8"（Ferrite） |
| HF：1×1.75"（Ferrite） | |
| Handling Power (AES) | LF：200W |
| HF：60W | |
| Maximum Peak SPL | 125dB/1m |
| Nominal Impedance | LF:8Ω / HF:8Ω |
| Connections | 2 x NL4 SpeakOn |
| Pin Connections | NL4=LF:+1-1 |
| Width | 250mm |
| Height | 400mm |
| Depth | 250mm |
| Weight | 11kg / 24lb |
| Rigging and Handling | |
| Handle | 1 handles |
| Threaded | 6x M6 threaded insert |
| Threaded | 2x M8 threaded insert |
| Pole socket | 1x 35mm Pole socket |
| Physical Data | |
| Material | Baltic Birch Plywood |
| Finish | Dark Grey |
| Front | Polyester powder-coated steel grill |
| Rigging | Steel |
| Protection rating | IP65 |
